Hardware Development of a Laboratory-Scale Microgrid Phase 1: Single Inverter in Island Mode Operation - Paperback

by National Renewable Energy Laboratory (Nr (Created by)

This report summarizes the activities of the first year of a three-year project to develop control software for micro-source distributed generation systems. The focus of this phase was on internal energy storage requirements, the modification of an off-the-shelf motor drive system inverter to supply utility-grade ac power, and a single inverter system operating in island mode. The report provides a methodology for determining battery energy storage requirements, a method for converting a motor drive inverter into a utility-grade inverter, and typical characteristics and test results of using such an inverter in a complex load environment.
