Creo Parametric 7.0: Design Documentation and Detailing - Paperback

by Ascent - Center for Technical Knowledge (Author)

The Creo Parametric 7.0: Design Documentation and Detailing learning guide is designed for all draftspersons that document designs using Creo Parametric. It focuses on how to use Creo Parametric to communicate design information from your part and assembly models.

This content was developed using Creo Parametric 7.0, Build 7.0.2.0.

Topics Covered

• View creation

• View manipulation

• Detailing a drawing

• Drawing notes

• Tolerances

• Assembly drawings

• Drawing tables

• 2D sketching

• Symbols


Prerequisites

• Access to the Creo Parametric 7.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.

• Completing Creo Parametric 7.0: Introduction to Solid Modeling or equivalent Creo Parametric 7.0 experience.
